What to look for

The curve never crosses itself and never closes. It orbits one wing an unpredictable number of times, jumps to the other, and comes back. Which wing it picks next is the part nobody can compute in advance.

The maths

dx/dt = σ(y − x)

σ is the Prandtl number. This term pulls x toward y at a rate set by the fluid viscosity.

dy/dt = x(ρ − z) − y

ρ is the Rayleigh number, the temperature difference driving the convection. Above ρ ≈ 24.74 the system stops settling and never repeats.

dz/dt = xy − βz

β is a geometric factor. The classic values are σ=10, ρ=28, β=8/3, which is what runs here.

How it is built

Classical fourth-order Runge-Kutta with dt = 0.005, fourteen steps per frame so the curve advances at a readable speed. The trail keeps the last 2,600 points and fades along its length. The projection is simply x on screen-x and z on screen-y: the famous butterfly is the shadow of a three-dimensional curve. The validation suite measures the largest Lyapunov exponent of this exact scheme against the published value.

The code, step by step

Cut straight from lab.js. These are the real lines that run above, not a simplified version.

Integrate the three equations

const dt = 0.005;
for (let i = 0; i < 14; i++) {
  const f = (a, b, c) => [P.sigma * (b - a), a * (P.rho - c) - b, a * b - P.beta * c], hh = dt / 2;
  // RK4. Con Euler explícito el exponente de Lyapunov salía 5,8 % alto
  // (lo midió la suite de validación de BN Lab Simulations); con RK4, 0,18 %.
  const k1 = f(x, y, z), k2 = f(x + hh * k1[0], y + hh * k1[1], z + hh * k1[2]);
  const k3 = f(x + hh * k2[0], y + hh * k2[1], z + hh * k2[2]);
  const k4 = f(x + dt * k3[0], y + dt * k3[1], z + dt * k3[2]);
  x += dt / 6 * (k1[0] + 2 * k2[0] + 2 * k3[0] + k4[0]);
  y += dt / 6 * (k1[1] + 2 * k2[1] + 2 * k3[1] + k4[1]);
  z += dt / 6 * (k1[2] + 2 * k2[2] + 2 * k3[2] + k4[2]);
  trail.push([x, y, z]);

Classical fourth-order Runge-Kutta: the derivative is sampled four times across the step and the samples are blended. Fourteen steps of dt = 0.005 per frame keep the curve smooth. It replaced forward Euler after a numerical check measured Euler's Lyapunov exponent 5.8 % above the published value. σ, ρ and β come from the sliders.

Rotate and project to 2D

const ang = M.in ? (M.x / w - 0.5) * 2.4 : 0;
const ca = Math.cos(ang), sa = Math.sin(ang);
const sc = Math.min(w, h) / 62, cx = w / 2, cy = h / 2 + h * 0.22;
const px = p => cx + (p[0] * ca - p[1] * sa) * sc;
const py = p => cy - p[2] * sc;

The attractor lives in three dimensions and the screen has two. Moving the cursor left and right rotates the view around the vertical axis before projecting, so you can look at the butterfly from the side.

Draw with a fading tail

for (let i = 1; i < trail.length; i++) {
  ctx.strokeStyle = `rgba(${acc},${((i / trail.length) * 0.75).toFixed(3)})`;
  ctx.beginPath();
  ctx.moveTo(px(trail[i - 1]), py(trail[i - 1]));
  ctx.lineTo(px(trail[i]), py(trail[i]));
  ctx.stroke();

Opacity is proportional to the index, so the oldest segments are nearly invisible and the newest is bright. That gradient is what reads as motion in a still frame.

Why it matters

Lorenz found it in 1963 by restarting a weather simulation from a printout rounded to three decimals instead of six. The forecast came out completely different. That accident is why we have a word for the butterfly effect and why weather forecasts have a horizon.

FULL

lab.js · lorenz

{ id: 'lorenz',
      name: L('Lorenz attractor', 'Atractor de Lorenz'),
      note: L('Deterministic and unpredictable. Never repeats, never escapes.',
              'Determinista e impredecible. Nunca se repite, nunca se escapa.'),
      params: [
        { key: 'rho',   label: L('Rayleigh ρ', 'Rayleigh ρ'),   min: 1,  max: 60, step: 0.5, def: 28 },
        { key: 'sigma', label: L('Prandtl σ', 'Prandtl σ'),     min: 1,  max: 20, step: 0.5, def: 10 },
        { key: 'beta',  label: L('Geometry β', 'Geometría β'),  min: 0.5, max: 5, step: 0.05, def: 8 / 3 }
      ],
      make() {
        let x = 0.01, y = 0, z = 0, trail = [];
        return {
          reset() { x = 0.01; y = 0; z = 0; trail = []; },
          step(ctx, w, h, t, acc, P, M) {
            const dt = 0.005;
            for (let i = 0; i < 14; i++) {
              const f = (a, b, c) => [P.sigma * (b - a), a * (P.rho - c) - b, a * b - P.beta * c], hh = dt / 2;
              // RK4. Con Euler explícito el exponente de Lyapunov salía 5,8 % alto
              // (lo midió la suite de validación de BN Lab Simulations); con RK4, 0,18 %.
              const k1 = f(x, y, z), k2 = f(x + hh * k1[0], y + hh * k1[1], z + hh * k1[2]);
              const k3 = f(x + hh * k2[0], y + hh * k2[1], z + hh * k2[2]);
              const k4 = f(x + dt * k3[0], y + dt * k3[1], z + dt * k3[2]);
              x += dt / 6 * (k1[0] + 2 * k2[0] + 2 * k3[0] + k4[0]);
              y += dt / 6 * (k1[1] + 2 * k2[1] + 2 * k3[1] + k4[1]);
              z += dt / 6 * (k1[2] + 2 * k2[2] + 2 * k3[2] + k4[2]);
              trail.push([x, y, z]);
            }
            if (trail.length > 2600) trail.splice(0, trail.length - 2600);
            // El mouse gira la proyección alrededor del eje vertical
            const ang = M.in ? (M.x / w - 0.5) * 2.4 : 0;
            const ca = Math.cos(ang), sa = Math.sin(ang);
            const sc = Math.min(w, h) / 62, cx = w / 2, cy = h / 2 + h * 0.22;
            const px = p => cx + (p[0] * ca - p[1] * sa) * sc;
            const py = p => cy - p[2] * sc;
            ctx.lineWidth = 1;
            for (let i = 1; i < trail.length; i++) {
              ctx.strokeStyle = `rgba(${acc},${((i / trail.length) * 0.75).toFixed(3)})`;
              ctx.beginPath();
              ctx.moveTo(px(trail[i - 1]), py(trail[i - 1]));
              ctx.lineTo(px(trail[i]), py(trail[i]));
              ctx.stroke();
            }
          }
        };
      }
    },
